BVN Air USA

Professional Series: WH85 Whole House Dehumidifier

Designed for residential housing and other conditioned spaces.

The WH85 Professional Series Whole House dehumidifiers are compact, durable and efficient. They have a built in digital humidity controller and are specifically designed to control excess moisture that contributes to poor indoor air quality, property damage, mold, comfort complaints, and possible liability risks. They can be used to condition living spaces, crawl spaces and other large spaces up to 15,000 cubic feet with an AHAM rated capacity (80F/60%RH) of 85 pints per day.

HOW IT WORKS

Our Professional Series dehumidifiers can be used in a variety of ways to control the humidity level in your entire home. In the simplest terms, when the humidity level exceeds the set point of the humidity controller, the dehumidifier will energize. The internal fan and compressor will turn on, forcing air to be drawn across the evaporator coil, which is cooler than the dew point of the air, allowing the coil to remove water from the air and exit via the drain. The air is then reheated as it flows across the condenser coil and distributed back into the conditioned space.

INSTALLATION

Whole House dehumidifiers are simple to install. They are designed to be connected to your HVAC system using the included duct adapters. They can also be suspended from the ceiling. The unit can be controlled using the built in digital control, by connecting it to your homes HVAC control system or by purchasing our optional digital remote control unit.

WHAT’S IN THE BOX

Includes: the WH60/85 Whole House dehumidifier, 2 10” duct adapter collars, 1 MERV-10 air filter, 1 drain hose and clamp, 1 power cord, and 1 Installation and Operations Manual.

Specifications and Downloads

Rated Condensate Capacity (80°F, 60%) 85 ppd
Rated Condensate Capacity (73°F, 60%) 58.43 ppd
Energy Factor 1.91 L/KWH
Refrigerant R32
F.L.A @Rated Conditions (80°F, 60%) 5.7A
Airflow @0.00" S.P. 201 CFM
Inlet Filter Merv-10
Supply/Return Duct 10" Collar
Sound Level 59 dBA
Fresh Air NA
Drain Connection 3/4" FPT
Coverage Area Up to 15,000 cu ft
Power Cord 10′
Operating Temperature Range 33-105° F
Operating Relative Humidity Range 36-90%
Weight 56 lbs.
Unit Dimensions 21.7" x 12" x 12"
Warranty 5 Years
Power Supply 115V/60Hz
Digital Display Yes
Auto Restart Yes
Gravity Drain System Yes
Ducted Length Up to 10′
Aluminum Coils Yes
